B6R

0.0 out of 5 (0)

✓ B6R/B24R rack can accommodate two B6s/B24s
✓ Scalable deployment by placing multiple units side by side
✓ Compact integration of accessories

About It

No additional information available for this product yet.

Get this product for

$706

Will be delivered to your location via DHL or UPS. Ask an agent if import tariffs apply.

DescriptionSpecificationsDownloadReviews ( 0 )

Description

B6D Tank (Technical Specifications)	Value
Outer Size	1420(L) x 575(W) x 620(H) mm
N.W. / G.W. (B6)	130kg / 180kg
N.W. / G.W. (B6D)	110kg / 166kg
Total Weight	230kg (with coolant and miners)
Input Voltage	3-phase 350-480V 50/60Hz
	Single-phase 200-277V 50/60Hz
Output Voltage	Single-phase 200-277V 50/60Hz
Cooling Capacity	30kW @ 30°C
Power Usage	400W (Max)
Operating Temperature	-10°C to 40°C
Display	1.32” OLED Screen
Coolant Volume	174L
Capacity	6 ASIC Miners
Network	100Mbps Ethernet Switch
External Cooling	Dry Cooler/Water Cooling Tower
Pipe Diameter	DN25 (External Thread Diameter 32mm)
Max Inlet/Outlet Temp	45/60°C
Noise (INoise)	55dB(A) at 10m Distance

B6D Dry Cooler (Technical Specifications)	Value
Outer Size	1560(L) x 440(W) x 952(H) mm
N.W. / G.W.	117kg / 133kg
Input Voltage	Single-phase 200-240V 50/60Hz
Heat Transfer	30kW @ 25°C
	20kW @ 35°C
Operating Temperature	-10°C to 40°C
Coolant Capacity	14L
Power	580W x 2
Air Volume	13,000m³/h
Noise	71dB(A) at 10m Distance
Pipe Diameter	DN25 (External Thread Diameter 32mm)
Pipeline Length	5m x 2

B6R Rack (Specification)	Value
Outer size	1519(L) * 614(W) * 2060(H) mm
Capacity	B6x2
