Powered by the NVIDIA Blackwell architecture and DLSS 4
Core Clocks: Extreme Performance: 2745 MHz (MSI Center) Boost: 2730 MHz (GAMING & SILENT Mode)
HYPER FROZR THERMAL DESIGN: An apex evolution of advanced thermal design that delivers unparalleled cooling and quiet operation.
STORMFORCE Fan: Seven fan blades, claw texturing, and a circular arc are designed for optimal airflow with minimal noise.
Advanced Vapor Chamber: Built-in Vapor Chamber swiftly transfers heat from the GPU and VRAM to the core pipe for optimal dissipation.
Core Pipes: Square-shaped Core Pipes maximize heat dissipation with the Vapor Chamber for superior cooling.
Filled Fins: Shaped fins cover the core pipes to reduce turbulence and enhance cooling performance.
Wave Curved 4.0: Precision-engineered wave edges with a high-low fin design enhance airflow and reduce turbulence.
Air Antegrade Fin 2.0: The fins feature a V-shaped cutout and a high-low design at the airflow passthrough to optimize flow efficiency.
An apex evolution of advanced thermal design that combines fans, core pipes, vapor chamber, and fin shape to unleash unparalleled cooling efficiency and silent performance.
| Marketing Name | GeForce RTX™ 5080 16G VANGUARD SOC LAUNCH EDITION |
| Model Name | G5080-16VGSL |
| Graphics Processing Unit | NVIDIA® GeForce RTX™ 5080 |
| Interface | PCI Express® Gen 5 |
| Core Clocks | - Extreme Performance: 2745 MHz (MSI Center) - Boost: 2730 MHz (GAMING & SILENT Mode) |
| CUDA® Cores | 10,752 Units |
| Memory Speed | 30 Gbps |
| Memory | 16GB GDDR7 |
| Memory Bus | 256-bit |
| Output | - DisplayPort x3 (v2.1b) - HDMI™ x1 (HDMI™ 2.1b: Up to 4K 480Hz or 8K 120Hz with DSC, Gaming VRR, HDR) |
| HDCP Support | Yes |
| Power Consumption | 360W |
| Power Connectors | 16-pin x1 |
| Recommended PSU | 850W |
| Card Dimensions | 357 x 151 x 66 mm |
| Weight (Card/Package) | 1945 g / 3991 g |
| DirectX Version Support | 12 Ultimate |
| OpenGL Version Support | 4.6 |
| Maximum Displays | 4 |
| G-SYNC® Technology | Yes |
| Digital Maximum Resolution | 7680 x 4320 |
