✔ Series: MEG Z790 ACE
✔ Colour: schwarz
✔ Form Factor: Extended ATX
✔ Item Height: 1.5 Centimeters
✔ Item Width: 2 Centimeters
✔ Product Dimensions: 6 x 2 x 1.5 cm; 3 kg
✔ Batteries: 1 Lithium Metal battery required (included)
✔ Item Model Number: MEG Z790 ACE
✔ Processor Socket: LGA 1700
✔ Memory Technology: DDR5
✔ Computer Memory Type: DIMM
✔ Maximum Memory Supported: 128 GB
✔ Memory Clock Speed: 7800 MHz
✔ Graphics Card Interface: PCI Express
Ships in 5 days from payment. For bulk inquiries, consult a live chat agent or call our toll-free number.
Intel 14th/13th/12th Gen, DDR5, PCIe 5.0, Wi-Fi 6E, Thunderbolt 4
The MSI MEG Z790 ACE motherboard is designed to maximize the performance of Intel 14th, 13th, and 12th Gen processors with its robust 24+1+2 power phase design and dual CPU power connectors. It supports DDR5 memory up to 7800+MHz and features dual Thunderbolt 4 ports, dual 2.5G LAN, and the latest Wi-Fi 6E technology. The motherboard also includes five M.2 slots, PCIe 5.0 slots, and an advanced cooling solution with stacked fin arrays and direct touch heat pipes. Ideal for extreme gaming and overclocking, it combines premium aesthetics with unparalleled performance.
| Category | Details |
|---|---|
| CPU Support | Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors |
| LGA 1700 | |
| Memory | 4x DDR5 UDIMM, Maximum Memory Capacity 192GB |
| Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz | |
| Max. overclocking frequency: | |
| • 1DPC 1R Max speed up to 7800+ MHz | |
| • 1DPC 2R Max speed up to 6600+ MHz | |
| • 2DPC 1R Max speed up to 6400+ MHz | |
| • 2DPC 2R Max speed up to 5600+ MHz | |
| Supports Intel® XMP3.0 OC | |
| Supports Dual-Controller Dual-Channel mode | |
| Supports non-ECC, un-buffered memory | |
| Onboard Graphics | 1x Type-C DisplayPort |
| Supports a maximum resolution of 4K 60Hz | |
| *Available only on processors featuring integrated graphics. | |
| **Graphics specifications may vary depending on the CPU installed. | |
| Onboard Thunderbolt | Thunderbolt chip JHL8540 |
| 2x Thunderbolt4 (USB-C) ports | |
| Supports up to 40Gbps transfer rate with Thunderbolt devices | |
| Supports up to 20Gbps transfer rate with USB4 devices | |
| Supports up to 10Gbps transfer rate with USB 3.2 devices | |
| Supports up to 5V/3A,15W power charging | |
| Each port can daisy-chain up to three Thunderbolt 4 devices or five Thunderbolt 3 devices | |
| Supports up to 8K display (need to connect the DisplayPort of the discrete graphics card to the Mini DisplayPort Input port on the back panel) | |
| Expansion Slot | 3x PCI-E x16 slot |
| PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) | |
| PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU) | |
| PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) | |
| *PCI_E1 slot will run at x8 speed when installing device in the PCI_E2 slot or M2_4 slot. | |
| **M2_4 slot will be unavailable when installing device in the PCI_E2 slot. | |
| Multi-GPU | AMD MULTI-GPU Support |
| Storage | 5x M.2 |
| M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices | |
| M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices | |
| M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices | |
| M.2_4 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280 devices | |
| M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 22110/2280/2260 devices | |
| 6x SATA 6G | |
| *M2_4 slot will be unavailable when installing in the PCI_E2 slot. | |
| **SATA7 will be unavailable when installing M.2 SATA SSD in the M2_5 slot. | |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices | |
| *SATA_A1_A2 do not support RAID function. | |
| USB | 4x USB 2.0 (Front) |
| 4x USB 3.2 Gen1 Type A (Front) | |
| 7x USB 3.2 Gen2 Type A (Rear) | |
| 1x USB 3.2 Gen2 Type C (Rear) | |
| 2x USB 3.2 Gen2x2 Type C (Front) | |
| *To achieve 60W PD fast charging for JUSB6, the PD_PWR1 connector needs to be connected to the power supply unit. | |
| **JUSB6 doesn’t support USB 2.0 device. | |
| LAN | 2x Intel® 2.5Gbps LAN |
| Wireless / Bluetooth | Intel® Wi-Fi 6E |
| The Wireless module is pre-installed in the M.2 (Key-E) slot | |
| Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps | |
| Supports 802.11 a/ b/ g/ n/ ac/ ax | |
| Supports Bluetooth® 5.3, FIPS, FISMA | |
| * Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11. | |
| ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11. | |
| Audio | Realtek® ALC4082 Codec + ESS ES9280AQ Combo DAC/HPA |
| 7.1-Channel USB High Performance Audio | |
| Supports S/PDIF output | |
| Supports up to 32-Bit/384 kHz playback on front panel | |
| Internal I/O | 1x Power Connector(ATX_PWR) |
| 2x Power Connector(CPU_PWR) | |
| 1x Front Type-C Quick Charge Connector(PD_PWR1) | |
| 1x CPU Fan | |
| 2x Pump Fan | |
| 5x System Fan | |
| 2x Front Panel (JFP) | |
| 1x Chassis Intrusion (JCI) | |
| 1x Water Flow connector | |
| 1x Slow Mode Booting Jumper(JSLOW) | |
| 1x Front Audio (JAUD) | |
| 2x Thermal Sensor connectors(T_SEN) | |
| 1x Tuning Controller connector(JDASH) | |
| 3x Addressable V2 RGB LED connector (JARGB_V2) | |
| 1x RGB LED connector(JRGB) | |
| 1x TPM pin header(Support TPM 2.0) | |
| 4x USB 2.0 ports | |
| 2x USB 3.2 Gen1 Type A ports | |
| 2x USB 3.2 Gen 2×2 Type C ports | |
| V-check point | |
| LED Feature | 1x EZ LED Control switch |
| 4x EZ Debug LED | |
| 1x 2-Digit Debug Code LED | |
| Back Panel Ports | Clear CMOS Button |
| Flash BIOS Button | |
| 2.5G LAN | |
| 2.5G LAN | |
| Thunderbolt 4 40Gbps (Type-C) | |
| Wi-Fi / Bluetooth | |
| Audio Connectors | |
| Smart Button | |
| USB 3.2 Gen 2 10Gbps (Type-C Display port) | |
| USB 3.2 Gen 2 10Gbps (Type-A) | |
| Mini DisplayPort Input (for Thunderbolt passthrough) | |
| Optical S/PDIF-Out | |
| Operating System | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB Dimension | E-ATX |
| 277mm x 304.8mm | |
| Weight | 2.2 kg |
| Chipset Manufacturer | INTEL Chipset |
| Socket | LGA 1700 |
| Form Factor | ATX |
| Color | Black |
