✓ GPU Architecture: AMD RDNA™ 3
✓ Stream Processors: 3456
✓ Compute Units: 54 CU (with RT + AI Accelerators)
✓ Memory Size / Bus: 12GB GDDR6 / 192-bit
✓ M emory Clock: 18 Gbps Effective
✓ Infinity Cache: 48MB
✓ Engine Clock: Boost Clock: Up to 2584 MHz, Game Clock: Up to 2226 MHz
✓ Interface: PCI-Express 4.0 x16
✓ Displays: Maximum 4 Displays
✓ Resolution: HDMI: 7680×4320, DisplayPort 2.1: 7680×4320
✓ Power Consumption: 240W Total Board Power
✓ Cooling System: Tri-X Cooling Technology (3 Fans)
✓ Form Factor: 2.5 slot, ATX
✓ Dimensions: 320mm (L) x 128.75mm (W) x 52.57mm (H)
✓ Minimum Power Supply: 700W
Ships 2-4 weeks after payment. All sales final. No returns or cancellations. For bulk inquiries, consult a live chat agent or call our toll-free number.
| Specification | Details |
|---|---|
| GPU Architecture | AMD RDNA™ 3 |
| Fabrication Process | 5nm |
| Engine Clock | Boost Clock: Up to 2584 MHz Game Clock: Up to 2226 MHz |
| Stream Processors | 3456 |
| Compute Units | 54 CU (with RT + AI Accelerators) |
| Ray Accelerators | 54 |
| Infinity Cache | 48MB |
| Memory Size / Bus | 12GB GDDR6 / 192-bit |
| Memory Clock | 18 Gbps Effective |
| Interface | PCI-Express 4.0 x16 |
| Displays | Maximum 4 Displays |
| Resolution | HDMI: 7680×4320 DisplayPort 2.1: 7680×4320 |
| Output Ports | 2x HDMI 2x DisplayPort |
| BIOS Support | UEFI |
| Game Index | 1440P |
| Cooling System | Tri-X Cooling Technology with 3 Fans |
| Power Consumption | 240W Total Board Power |
| Power Connectors | 2 x 8-pin Power Connector |
| Minimum Power Supply | 700W |
| Form Factor | 2.5 slot, ATX |
| Dimensions | 320mm (L) x 128.75mm (W) x 52.57mm (H) |
| Supported OS | Linux®, Windows® 10, Windows® 11 (64-bit) |
| Sapphire Features | Intelligent Fan Control Precision Fan Control Two-Ball Bearing Fans Metal Backplate Red LED SAPPHIRE Logo |
| AMD Smart Technologies | AMD Noise Suppression AMD FidelityFX™ Super Resolution AMD FreeSync™ Technology AMD Link |
| Other Features | Microsoft® DirectX® 12 Ultimate Support Vulkan® Optimized AMD Radiance Display™ Engine |
| System Requirements | PCI Express® X16 lane Minimum 8GB system memory (16GB recommended) |
No reviews available.
