BC40 Basic-DryCooler

0.0 out of 5 (0)

✓ Dimensions (LWH) (mm): 12192*2438*2896
✓ Operating Weight (+): 23
✓ Coolant Volume (L): 13000
✓ Circulation Mode (L): Single loop
✓ Supported Qty of Miners: 384 S19/480 M50
✓ Qty of Tanks: B24 Tank*16
✓ Operating Temperature (°C): -25 ~ 55 (**) ,
✓ Input Voltage: 3-phase 350-480V 50/60Hz
✓ Max Power Load (MW): 1.58
✓ Output Voltage: 3-phase 350-480V 50/60Hz
✓ Certification: CE/UL
✓ Nominal Power for Cooling (kW): 96
✓ Power Distribution Cabinets Current (A): 1200A*2
✓ PDU Smart Meter: *16
✓ Cooling Capacity (MW): 1.34
✓ Cooling Type: Closed-circle water cooling tower / Dry cooler
✓ Inlet Temperature (°C): 45
✓ Outlet Temperature (°C): 60
✓ Design Reference Temperature (°C): 30

Available Variants:

BC40 Basic-Water Cooling Tower BC40 Basic-DryCooler BC40 coolant 13,000L BC20 Basic-Water Cooling Tower BC20 Basic-DryCooler BC20 coolant 6,000L BC40 Pro-Water Cooling Tower BC40 Pro-DryCooler BC20 Pro-Water Cooling Tower BC20 Pro-DryCooler

About It

No additional information available for this product yet.

Get this product for

$231,984.00

Will be delivered to your location via DHL or UPS. Ask an agent if import tariffs apply.

Lead time is 45 days. Shipping will be quoted separately at the time of loading as costs change weekly. Expect door-to-door shipping to range between $14,000-$17,000 USD to North America, and slightly less for Middle East. Buyer is responsible for renting crane to offload container from flatbed.

DescriptionSpecificationsDownloadReviews ( 0 )

Description

Specification	BC40	BC20	BC10	BC10 Semi
Basic/Pro	Basic	Pro	Basic	Pro
Dimensions (LWH) (mm)	1219224382896	582024382896	299124382591	299124382591
Shipping Weight (T)	13	7	3	2
Weight (T)	23	12	6	4
Coolant Capacity (L)	14000	7000	3600	1800
Circulation Mode	Single loop	Single loop	Single loop	Single loop
Miner Capacity	13384 S19/M50	384 S19/480 M50	192 S19/M50	192 S19/240 M50
				96 S19/120 M50
				48 S19/60 M50
Tank Quantity	B24 Tank * 16	B24 Tank * 8	B24 Tank * 4	B24 Tank * 2
Temperature	-25° C~40° C	-25° C~40° C	-25° C~40° C	-25° C~40° C
Electrical Performance (- /√ optional/standard)
Input Voltage and Frequency	3-phase 350-480V 50/60Hz	3-phase 350-480V 50/60Hz	3-phase 350-480V 50/60Hz	3-phase 350-480V 50/60Hz
Max Power Load (kW)	1693	2833	889	1411
Output Voltage and Frequency	Single-phase 200-277V 50/60Hz	Single-phase 200-277V 50/60Hz	Single-phase 200-277V 50/60Hz	Single-phase 200-277V 50/60Hz
Certification	CE/UL	CE/UL	CE/UL	CE/UL
Power (kW)	100	134	50	67
Power Distribution Cabinets (A)	1200Ax1 *2	1000Ax2 *2	630Ax1 *2	1000Ax1 *2
				630Ax1 *1
				1000Ax1 *1
				400Ax1 *1
				630Ax1 *1
PDU	Smart PDU*16	Smart PDU*32	Smart PDU*8	Smart PDU*16
Smart Meter	-	√	-	√
Integrated Wiring	√	√	√	√
Network	√	√	√	√
UPS	-	-	-	-
SPD	√	√	√	√
Cooling Capacity (kW)	1440	1920	720	960
Cooling Type	Closed water cooling tower / Dry cooler	Closed water cooling tower / Dry cooler	Closed water cooling tower / Dry cooler	Closed water cooling tower / Dry cooler
Inlet Temperature (° C)	45	45	45	45
Outlet Temperature (° C)	60	60	60	60
Design Reference Temperature (° C)	35	35	35	35
Container Components (- /√ optional/standard)
LED Lighting System	√	√	√	√
Ventilation System	√	√	√	√
Air Filter	√	√	√	√
Remote Temperature Sensors	√	√	√	√
Remote Smoke Sensors	√
