The Intel Xeon Gold 6534 is a server/workstation processor with 8 cores, launched in December 2023, at an MSRP of $2816. It is part of the Xeon Gold lineup, using the Emerald Rapids-SP architecture with Socket 4677. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 16 threads. To further increase overall system performance, up to two Xeon Gold 6534 CPUs can work together in a multi-processor (SMP) configuration. Xeon Gold 6534 has 22.5 MB of L3 cache and operates at 3.9 GHz by default, but can boost up to 4.2 GHz, depending on the workload. Intel is making the Xeon Gold 6534 on a 10 nm production node, the transistor count is unknown. The multiplier is locked on Xeon Gold 6534, which limits its overclocking potential.
With a TDP of 195 W, the Xeon Gold 6534 is extremely power hungry, which means you need top-notch cooling. Intel's processor supports DDR5 memory with an eight-channel interface. The highest officially supported memory speed is 4800 MT/s. ECC memory is supported, too, which is an important capability for mission-critical systems, to avoid data corruption. For communication with other components in the system, Xeon Gold 6534 uses a PCI-Express Gen 5 connection. This processor lacks integrated graphics, you might need a graphics card.
Power consumption195W
Processor core available8 core
Processor cache22.5 MB L3
Processor speed3.9 GHz
PlatformRefer to QuickSpecs for detailed information
Processor modelIntel® Xeon® Gold 6534
Maximum memory speed4800 MT/s
