BC20 Basic-DryCooler

0.0 out of 5 (0)

Dimensions (LWH) (mm): 12192*2438*2896

Operating Weight (+): 23
Coolant Volume (L): 13000
Circulation Mode (L): Single loop
Supported Qty of Miners: 384 S19/480 M50
Qty of Tanks: B24 Tank*16
Operating Temperature (°C): -25 ~ 55 (**) ,
Input Voltage: 3-phase 350-480V 50/60Hz
Max Power Load (MW): 1.58
Output Voltage: 3-phase 350-480V 50/60Hz
Certification: CE/UL
Nominal Power for Cooling (kW): 96
Power Distribution Cabinets Current (A): 1200A*2
PDU Smart Meter: *16
Cooling Capacity (MW): 1.34
Cooling Type: Closed-circle water cooling tower / Dry cooler
Inlet Temperature (°C): 45
Outlet Temperature (°C): 60
Design Reference Temperature (°C): 30

Lead time is 45 days. Shipping will be quoted separately at the time of loading as costs change weekly. Expect door-to-door shipping to range between $14,000-$17,000 USD to North America, and slightly less for Middle East. Buyer is responsible for renting crane to offload container from flatbed.

BC40 Basic-Water Cooling TowerBC40 Basic-DryCoolerBC40 coolant 13,000LBC20 Basic-Water Cooling TowerBC20 Basic-DryCoolerBC20 coolant 6,000LBC40 Pro-Water Cooling TowerBC40 Pro-DryCoolerBC20 Pro-Water Cooling TowerBC20 Pro-DryCooler

About It

No additional information available for this product yet.
Get this product for
$125,592.00
vipera
vipera
Will be delivered to your location via DHL or UPS. Ask an agent if import tariffs apply.
    SpecificationBC40 MEGABC20 MEGABC10 MEGA
    Size12192×2438×2896 mm5820×2438×2896 mm2991 x 2438 × 2591 mm
    Amount of machinesB24 tanks * 16B24 tanks * 8B24 tanks * 4
    RacksB24R racks * 8B24R racks * 4B24R racks * 2
    Input voltage3-phase 350-480V 50/60Hz3-phase 350-480V 50/60Hz3-phase 350-480V 50/60Hz
    Power load (max)2.02MW@35°C1.02MW@35°C0.52MW@35°C
    Output voltage200-277V, 50/60Hz200-277V, 50/60Hz200-277V, 50/60Hz
    Network1000Mbps Ethernet switch *21000Mbps Ethernet switch *11000Mbps Ethernet switch *1
    LightingLEDsLEDsLEDs
    VentilationExhaust fansExhaust fansExhaust fans
    External coolingDry cooler or closed-circuit water cooling towerDry cooler or closed-circuit water cooling towerDry cooler or closed-circuit water cooling tower
    CertificationElectrical – UL Classification or ETL / Container- CSCElectrical – UL Classification or ETL / Container- CSCElectrical – UL Classification or ETL / Container- CSC
    Channel width0.8m safety and maintenance channel space0.8m safety and maintenance channel space0.8m safety and maintenance channel space
    Internal systemIncluding B24 tanks, B24R racks, Circulation system, Power distribution, NetworkIncluding B24 tanks, B24R racks, Circulation system, Power distribution, NetworkIncluding B24 tanks, B24R racks, Circulation system, Power distribution, Network
    External connectorDN65*32 (2 connectors of each tank)DN65*32 (2 connectors of each tank)DN65*32 (2 connectors of each tank)
    OthersMore than 10-year lifetime for the containerMore than 10-year lifetime for the containerMore than 10-year lifetime for the container
    Can withstand strong wind damage of 60 m/sCan withstand strong wind damage of 60 m/sCan withstand strong wind damage of 60 m/s
    Emergency protection in case of power failure and water supply failureEmergency protection in case of power failure and water supply failureEmergency protection in case of power failure and water supply failure
