✔ Product SKU: ARS-111GL-NHR
✔ Motherboard: Super G1SMH-G
✔ Processor: NVIDIA 72-core Grace CPU on GH200 Grace Hopper™ Superchip
✔ Memory:
✔ Chipset: System on Chip
✔ I/O Ports:
✔ BIOS Type: AMI 64MB SPI Flash EEPROM
✔ Power Management:
✔ Power Supply: 2x 2000W Redundant Titanium Level (96%)
✔ Available: Used Condition
The Stock is 3Months Used, and available in USA for Immediate Pickup. All sales final. No returns or cancellations. For bulk inquiries, consult a live chat agent or call our toll-free number.
High-Performance Supermicro ARS-111GL-NHR
NVIDIA GH200 Grace Hopper™ Superchip
The Supermicro ARS-111GL-NHR is a powerful, AI-focused server featuring the NVIDIA GH200 Grace Hopper™ Superchip with up to 72 cores and 144 threads. Designed for heavy workloads, this 1U rackmount system supports up to 480GB of ECC LPDDR5X memory and 96GB of additional HBM3 GPU memory. It offers robust expandability with dual PCIe 5.0 slots and hot-swappable E1.S NVMe drives, making it ideal for high-performance computing, deep learning, and advanced AI applications. This system ensures reliable performance with dual 2000W redundant Titanium Level power supplies and sophisticated monitoring for optimal thermal management.
| Component | Specification |
|---|---|
| Product SKU | ARS-111GL-NHR (Silver) |
| Motherboard | Super G1SMH-G |
| Processor | NVIDIA GH200 Grace Hopper™ Superchip |
| Core Count | Up to 72C/144T |
| CPU Notes | Supports up to 1000W TDP CPUs (Air Cooled) |
| Max GPU Count | Up to 1 onboard GPU |
| Supported GPU | NVIDIA GH200 Grace Hopper™ Superchip (Air-cooled) |
| CPU-GPU Interconnect | NVLink®-C2C |
| Memory Slot Count | Onboard Memory |
| Max Memory | Up to 480GB ECC LPDDR5X |
| Additional GPU Memory | Up to 96GB ECC HBM3 |
| Chipset | System on Chip |
| LAN | 1 RJ45 1GbE (Dedicated IPMI port) |
| USB | 2 USB 3.0 ports (Rear) |
| BIOS Type | AMI 64MB SPI Flash EEPROM |
| PC Health Monitoring | |
| – CPU Monitoring | Monitors for CPU Cores, Chipset Voltages, Memory |
| – Fan Monitoring | Tachometer monitoring, PWM fan connectors, Speed control |
| – Temperature Monitoring | Monitoring for CPU and chassis environment, Thermal Control for fan connectors |
| Form Factor | 1U Rackmount |
| Chassis Model | CSE-MG102TS-R000NDFP |
| Dimensions (H x W x D) | 1.75″ (44mm) x 17.33″ (440mm) x 37″ (940mm) |
| Package Dimensions | 9.5″ (H) x 48″ (W) x 28″ (D) |
| Weight | Net: 48.5 lbs (22 kg), Gross: 65.5 lbs (29.7 kg) |
| Available Color | Silver |
| PCIe Expansion Slots | 2 PCIe 5.0 x16 FHFL slots |
| Drive Bays | 8x E1.S hot-swap NVMe drive slots |
| M.2 Slots | 2 M.2 NVMe slots |
| System Cooling | 9 Removable heavy-duty 4CM Fans |
| Power Supply | 2x 2000W Redundant Titanium Level power supplies |
| Power Supply Dimensions | 73.5 x 40 x 185 mm |
| AC Input | |
| – 1000W | 100-127Vac / 50-60Hz |
| – 1800W | 200-220Vac / 50-60Hz |
| – 1980W | 220-230Vac / 50-60Hz |
| – 2000W | 220-240Vac / 50-60Hz (for UL only) |
| – 2000W | 230-240Vac / 50-60Hz |
| – 2000W | 230-240Vdc / 50-60Hz (for CQC only) |
| +12V Output | |
| – 100Vac-127Vac | Max: 83A / Min: 0A |
| – 200Vac-220Vac | Max: 150A / Min: 0A |
| – 220Vac-230Vac | Max: 165A / Min: 0A |
| – 230Vac-240Vac | Max: 166A / Min: 0A |
| 12V SB Output | Max: 3.5A / Min: 0A |
| Output Type | Backplanes (gold finger) |
| Operating Temperature | 10°C ~ 35°C (50°F ~ 95°F) |
| Non-operating Temperature | -40°C to 60°C (-40°F to 140°F) |
| Operating Humidity | 8% to 90% (non-condensing) |
| Non-operating Humidity | 5% to 95% (non-condensing) |
