Power Supply APW11 Bitmain APW11 17v-21.6v for Antminer S19 Hyd./ T19 Hyd./ S19 Pro+ Hyd.
| Parameter | APW11 |
|---|---|
| OUT1 | |
| DC Voltage | 17V-21.6V |
| Rated Current (380V input) | 300A |
| Rated Power (380V input) | 6500W |
| Ripple & Noise | <1% |
| Line Regulation | <1% |
| Load Regulation | <1% |
| Setup Time | <5S |
| Short Circuit Protection | >10mS |
| OUT2 | |
| DC Voltage | 12V |
| Rated Current (220V input) | 1A |
| Ripple & Noise | <1% |
| Voltage Accuracy | 12.2V—12.4V |
| Line Regulation | <1% |
| Load Regulation | <1% |
| Setup Time | <5S |
| Short Circuit Protection | >10mS |
| Input | |
| Voltage Range | 380-415V AC |
| Frequency Range | 50~60 Hz |
| Power Factor | >0.99 (full load) |
| Leakage Current | <1.5mA (380V 50Hz) |
| Protection | |
| Low-voltage Input | <304V AC |
| Output Short Circuit | Yes |
| Overheat Protection | Yes |
| Over-current Output | 300A-350A |
| Environment | |
| Operating Temperature | -20-45℃ |
| Operating Humidity | 20%-90%RH (non–condensing) |
| Altitude | <2000m |
| Structure | |
| Dimensions | 320mm179mm63mm |
| Net Weight | 5kg |
| Cooling System | |
| Cooling Type | Water cooling |
| Inlet Temperature | 20-35 ℃ |
| Water Flow Rate | 8L/min |
| Water Pressure | 3 BAR |
